Keyence SL-R11E safety light curtain controller - Used
Description
Keyence SL-R11E safety light curtain controller, used. Made in Japan. 24 V.
Specifications
| Brand | Keyence |
|---|---|
| Model | SL-R11E |
| Origin | Japan |
| Leakage current | 100 µA max. |
| Max. load current | 500 mA |
| OFF-state voltage | 2 V |
| Power voltage | 24 VDC ±10 %, Ripple (P-P) ≤10 % |
| Weight | Approx. 350 g |
| Storage temperature | -10 to +60 °C / 14 to 140 °F (No freezing) |
| Operating ambient temperature | -10 to +55 °C / 14 to 131 °F (No freezing) |
| Vibration resistance | 10 to 55 Hz, Double amplitude 0.7 mm / 0.03", 20 sweeps in each of the X, Y, and Z directions |
| AUX | 24 VDC 50 mA max. residual voltage 2 V max. |
| Current consumption | ≤100 mA (for SL-R11E only) |
| Enclosure rating | IP20 (IEC60529) |
| Load wiring resistance | 10 Ω max Ω |
| Material | Polycarbonate |
| Max. capacitive load | 2.2 µF (When load resistance 100 Ω) |
| Operating relative humidity | 35 to 85 % RH (No condensation) |
| OSSD output type | PNP open collector |
| Response speed FSD1, 2 AUX | 20 ms (including sensor response time) |
| Response speed when E-STOP is input | 20 ms |
| Shock resistance | 100 m/s² (Approx. 10 G), 16 ms pulse, 1,000 times in each of the X, Y, and Z directions |
| Storage relative humidity | 35 to 95 % RH (No condensation) |
